T-05

Description

  • Die-casting aluminium body, PC prism transparent diffuser.
  • Optics with PC lens with high visual comfortable and uniform lighting distribution, multiple light distribution options.
  • High quality LED chips, Driver with 0-10V/DALI/programmed options, and with surge protection up to 20KV.
  • The light source of the lighting is set at the top, and it is easy to replace by using zhaga PCB board.
  • Surface anti-ultravilet pure polyester powder painting, Corrosion resistance can be more than 1000 hours.
  • No photo-biological risk, (no risk linked to infrared, blue light and UV radiation) in accordance with EN 62471:2008.
  • Street lighting control used with smart control technology. It can be compatible with remote management system.
  • All external screws are made of 304 stainless steel.
Lamp power: 40-75W
Output lumen:  4800-9000LM
Specification of lam ps: Vertical mounting
Color temperature option: 3000K/4000K
IP grade:  IP65
IK level: IK09
Installation pipe diameter: Ø60/Ø76mm

DOWNLOADS

Download Brochure Installation Guide Photometric Photometric
