Home / Product / Flood Lighting / Inground Lighting / M-04

M-04

Description

  • Die-casting aluminium body, 304 stainess steel fram.
  • 10mm higher hardened temperated glass, it ensure pass IK10 standared test.
  • Mutiple optics options, it with high visual comfort and good anti glare effect.
  • High temperature resistant and waterproof silicone rubber ring, corrosion resistant PP plastic installion housing.
  • Floor/ground/wall-mounted recessed luminaire intended applications as required.
  • No photo-biological risk, in accordance with EN 62471:2008.
  • All external screw are made of 304 stainless steel.
Power: 6-12W
Light flux LM: 420-1200LM
CCT: 3000K / 4000K / RGBW
Options: Switch/DMX
Input volltage: DC 24V / AC 100-240V
Nominal efficacy: 70-100 Lm/W (Ra80)
Installation method： Floor-mounted/Wall-mounted
Lengths (range cm) -

DOWNLOADS

Download Brochure Specification Installation Guide Photometric

Application

Technology data

Optical application
